PCB Overview

The Moto32 PCB is a compact, multi-layer board designed specifically for motorcycle applications, featuring automotive-grade protection and robust construction.

PCB Specifications

Physical Characteristics

Surface Finish Options

Color Options

While purely aesthetic, PCB color can help with assembly and debugging:

• Black: Professional appearance, hides components
• Blue: High contrast for component identification
• Green: Standard color, good visibility
• Red: Eye-catching, shows traces clearly

PCB Layout

Top Side Components

Major Components (Top):

• U1: ESP32-S3-WROOM-1-N8R2 module (main MCU)
• U2: CH340C USB-to-UART converter
• U3: AP63203WU-7 buck converter
• Q5-Q12: 8x DMP4015SK3Q-13 MOSFET switches
• USB-C1: TYPE-C-31-M-12 connector
• Various: Capacitors, resistors, protection diodes

Bottom Side

The bottom layer typically contains:

• Ground plane
• Additional routing
• Thermal relief pads
• Component markings

Layer Stackup

Typical Multi-Layer Structure:

┌─────────────────────┐
│  Top Copper (L1)    │ ← Component side, signal traces
├─────────────────────┤
│  Dielectric         │
├─────────────────────┤
│  Inner Layer (L2)   │ ← Ground plane
├─────────────────────┤
│  Dielectric         │
├─────────────────────┤
│  Inner Layer (L3)   │ ← Power plane (12V, 3.3V)
├─────────────────────┤
│  Dielectric         │
├─────────────────────┤
│  Bottom Copper (L4) │ ← Additional routing, ground
└─────────────────────┘

Design Sections

Power Supply Section

12V Input → 3.3V Regulated Output

Components:

• U3 (AP63203WU-7): Switching buck converter
  • Input: 12V nominal (9-16V tolerance)
  • Output: 3.3V @ 2A max
  • Efficiency: >90% typical
• D1 (SS34): Input protection Schottky diode
• C2, C10, C11: Output filtering capacitors
• L1: Output inductor (if present)

Features:

• Wide input voltage range (automotive transients)
• Thermal shutdown protection
• Current limiting
• Stable 3.3V for ESP32 and logic

USB Interface Section

USB-C to Serial Converter

Components:

• USB-C1: USB Type-C connector
• U2 (CH340C): USB-to-UART bridge
• X1: 12MHz crystal for CH340C
• D4, D5: TVS diodes for USB protection
• R18-R21: USB data line resistors

Features:

• USB-C connector (modern standard)
• Automatic driver installation (CH340)
• ESD protection on USB lines
• 115200 baud default communication

ESP32-S3 Section

Main Microcontroller

Components:

• U1 (ESP32-S3-WROOM-1): Main MCU module
• C1, C3-C9: Decoupling capacitors
• R1: EN pull-up resistor
• R2: Boot mode resistor
• Programming header: UART0 connections

Features:

• Dual-core Xtensa LX7 @ 240MHz
• 8MB Flash, 2MB PSRAM
• Wi-Fi 802.11 b/g/n
• Bluetooth 5.0 LE
• Rich GPIO and peripheral set

MOSFET Output Section

8x High-Side Switches

Components per channel:

• Q5-Q12 (DMP4015SK3Q-13): P-channel MOSFET
  • RDS(on): Low resistance
  • Max current: Per datasheet
  • Logic-level gate drive
• R6-R17: Gate resistors (10kΩ)
• Pull-up resistors: Keep outputs off by default

Features:

• Logic LOW activates output (pulls gate to GND)
• Logic HIGH or floating keeps output OFF
• Suitable for automotive loads (lights, horn, etc.)
• Short-circuit tolerant (with proper fusing)

Output Channel Mapping:

Protection Circuits

Multi-Layer Protection:

• TVS Diodes (D4, D5): Transient voltage suppression
  • Clamp voltage spikes from ignition, starter motor
  • Protect sensitive electronics
• Schottky Diode (D1): Reverse polarity protection
• Fuse: External 10A inline fuse recommended
• Decoupling Capacitors: Filter noise on power rails
• Ground Planes: Low impedance return path

Design Considerations

Automotive Environment

The PCB is designed for harsh motorcycle conditions:

Vibration Resistance:

• Multiple ground plane stitching vias
• Large solder pads for through-hole components
• Mechanical support for heavy components (ESP32 module)

Temperature Range:

• Components rated for automotive temps (-40°C to +85°C)
• Adequate spacing for thermal expansion
• Heat dissipation considerations for MOSFETs

Moisture Protection:

• Conformal coating recommended for exposed installations
• No exposed copper on edges
• Sealed connectors preferred

Electrical Noise:

• Ground planes for EMI shielding
• Decoupling capacitors near every IC
• Separate analog and digital grounds (if applicable)
• Twisted pair or shielded wires for sensors

PCB Images

3D Render

Features visible:

• Component placement and orientation
• Connector positions
• Mounting hole locations
• Overall board dimensions

Schematic Preview

See the Schematics page for detailed circuit diagrams.

Manufacturing Notes

For PCB Manufacturers

When ordering, specify:

PCB Specifications:
  Material: FR-4
  Layers: Multi-layer (auto-detect from Gerber)
  Thickness: 1.6mm
  Surface Finish: ENIG preferred, HASL acceptable
  Copper Weight: 1 oz (35µm)
  Solder Mask: Your choice (blue/black recommended)
  Silkscreen: White (on dark colors) or black (on light colors)
  Min Trace/Space: As designed in Gerber
  Min Hole Size: As designed in Gerber
  Edge Connector: No
  Castellated Holes: No

For Assembly Services

Provide these files:

• Gerber package (Gerber_Canarin_MUX_PCB.zip)
• BOM (BOM_Canarin_MUX.csv)
• Pick & Place (PickAndPlace_PCB_Canarin_MUX.csv)

Assembly Notes:

• All components are SMD (surface mount)
• Smallest packages: 0402 (resistors/capacitors)
• Some components may require manual placement
• Reflow profile: Lead-free SAC305

Testing Points

Recommended Test Points:

Design Files

All design files are available in the repository:

Modifications & Customization

The open-source nature allows you to modify the PCB:

Common Modifications:

• Add more MOSFET channels for additional outputs
• Include current sensing resistors for monitoring
• Add CAN bus transceiver for vehicle communication
• Include IMU for lean angle sensing (auto-cancel)
• Add relay drivers for higher current loads
• Include voltage dividers for analog input reading

Before Modifying:

1. Review the schematic thoroughly
2. Understand the circuit operation
3. Check component datasheets
4. Verify electrical ratings
5. Run design rule checks (DRC)
6. Prototype and test before production
